Variable Temperature Microplate Sealer VTS

V902001

The Vitl VTS is a variable temperature heat sealer for a wide range of microplates. The VTS is designed to deliver consistent sealing in low to medium throughput laboratories.

Features :

  • User-variable time and temperature settings via an intuitive keypad
  • Unique, ergonomic lever action, specifically designed to avoid repetitive strain injury
  • One-time seal with uniform heat distribution meaning there is no need to rotate or reseal
  • Audible and visual feedback on LED display to ensure consistent, repeatable microplate sealing

More details

Description
Applications
Specifications
Related products
Resources

Description

To give you maximum flexibility without compromising on sealing quality, the VTS microplate heat sealer allows you to adjust the heating temperature and define a sealing time (the time that the microplate should be in contact with the heated surface). Coupled with an audible alarm indicating correct sealing pressure, the VTS provides optimal sealing control and  consistency.

In practice, this means that you can quickly and securely seal multiple varieties of microplates over and over again.

Just set a temperature and time and wait for the countdown to finish.

Specifications

Sealing temperature range125 - 200°C in 1°C increments
Sealing time range1-9 seconds in 0.5 second increments
Warm up time up to 170°C< 10 minutes
Dimensions (W x D x H)22.0 x 32.5 x 42.5 cm
Power supply110-120 / 220-230 VAC nominal
Weight7.2 kg

Applications

  • Very low temperature sample storage with solvent resistance
  • Sample integrity
  • Secure, long term sample storage
  • PCR with water thermal cyclers
